OPERATION
3. Open the steering lock-out valve by turning the handle
(A) to t he ho rizontal position.
Figure 3.76: Steering Lock-Out Valve in
Open Position
4. Open the lock-out valve (A) on each lift cylinder by
turning the hand l e to the vertical position.
Figure 3.77: Lift Cylinder Lock-Out Valve
3.14.6 Road Friendly Transport
™
Option
The optional Road Friendly Transport
™
system allows the
mower conditioner to be towed while remaining within the
legal width restrictions on most roads and highways.
Figure 3.78: Road Friendly Transport
™
System
147910
72
Revision A
