MAINTENANCE AND SERVICING
12. Close cutterbar doors. Refer to 3.3.3 Closing Cutterbar
Doors, page 38.
Figure 4.117: Cutterbar Doors in
Closed Position
Removing Non-Driven Rotary Deflectors
DANGER
To avoid bodily injury or death from unexpected start-up or fall of a raised machine, stop engine, remove
key, and engage header lift cylinder lock-out valves before going under machine for any reason.
CAUTION
Exercise caution when working around the blades. Blades are sharp and can cause serious injury. Wear
gloves when handling blades.
1. Open cutterbar doors. Refer to 3.3.1 Opening
Cutterbar Doors, page 36.
Figure 4.
118: Cutterbar Doors
147910
17
