MAINTENANCE AN D SERVICING
3. Remove two nuts (A) from bolt studs.
4. Remove the square neck carriage head bolt (B), slide
out the bracket, and remove curtain (C).
Figure 4.
79: Outboard Curtain
Instal
ling Outboard Curtains
The p ro cedure fo r installing outboard c urta in s is the same for both sides.
1. Open cutterbar door. Refer to 3.3.1 Opening C utterbar
Doors, page 36.
Figure 4.80: Cutterbar Doors
147910 157 Revision A
