MAINTENANCE AND SERVICING
4.9 Conditioners
4.9.1 Roll Conditioner
Inspecting Roll Conditioner
DANGER
To avoid bodily injury or death from unexpected start-up or fall of a raised machine, stop engine, remove
key, and engage header lift cylinder lock-out valves before going under machine for any reason.
CAUTION
Exercise caut
ion when working around the blades. Blades are sharp and can cause serious injury. Wear
gloves when ha
ndling blades.
1. Lower mower conditioner fully, stop engine, and
remove key.
2. Engage lift cylinder lock-out valves. Refer to 3.1.1
Engaging Locks, page 31.
3. Remove left and right driveshields (A). Refer to 4.8.1
Removing Driveshields, page 224.
Figure 4.248: Driveshields
4. Inspect left side roll conditioner bearing (A) for signs of
wear or damage.
Figure 4.249: Left Side Roll Conditioner Bearing
147910 228 Revision A
