MAINTENANCE AND SERVICING
CAUTION
Exercise caution when working around the blades.
Blades are sharp and can cause serio us injury. Wear
gloves when handling blades.
5. Use a level to ensure the cutterbar is level
in b o th directions. Raise or lower mower
conditioner accordingly.
Figure 4.19: Spirit Level on Cutterbar
6. Remove oi
l level ins pe ct ion plug (A) and O-ring (B)
from cutt
erbar.
7. Add SAE 90
lubricant if require d (oil level must be up
to the bo
re). Refer to Filling Cutterbar, page 130.
8. Check O-r
ing (B) for breaks or cracks and replace
if neces
sary.
9. Install
plug (A) and O-ring (B). Tighten securely.
Figure 4.20: Inspection Plug and O-ring
147910 128 Revision A
