TROUBLESHOOTING
Symptom
Problem
Solution Refer to
Rolls not crimping
crop sufficiently
Decrease roll gap.
3.15.6 Roll Gap, page 85
Slow crop drying
Crop is bunched
in windrow
Adjust forming shields/baffle.
3.15.9 Forming Shields: Roll
Conditioner, page 90,
Forming Shields: Finger
Conditioner, page 96,and
Internal Intensity Baffle, page
92.
Excessive crimping Increase roll gap.
3.15.6 Rol
l Gap, page 85
Excessive drying
or bleaching
of crop
Crop is spread too
wide in windrow
Adjust forming shields.
3.15.9 Forming Shields: Roll
Conditioner, page 90,or
Forming Shields: Finger
Conditioner, page 96.
Plugging
behind e
nd
rotary d
eflectors
Ground speed
too slow
Increas
e ground speed.
3.15.4 Ground Speed, page 84
Poorly formed or
bunchy w indrows
Forming shields not
properly adjusted
Adjust forming shields.
3.15.9 Forming Shields: Roll
Conditioner, page 90,or
Forming Shields: Finger
Conditioner, page 96.
Windro w too wide
(finger conditioner)
Crop not throwing
far enough
Adjust internal intensity baffle, or
adjust finger rotor speed.
Internal Intensity Baffle, page
92,or
Finger Rotor Speed, page 92.
