F1–50
ON-BOARD DIAGNOSTIC
OUTLINE
A6E397018881201
• The construction and operation of the on-board diagnostic system is essentially carried over from that of the
current Mazda6 (GG), except for the following. (See Mazda6 Training Manual 3359-1*-02C.)
4WD ATX model
— DTCs, PID monitoring items, and simulation items have been deleted to match the vehicle characteristics.
Unleaded fuel (RON 90 or above) model
— DTCs and PID monitoring items which relevant to BARO sensor have been deleted to match the vehicle
characteristics.
End Of Sie
CONTROL DEVICE AND MONITORING SYSTEM RELATIONSHIP CHART
A6E397018881202
Monitoring System
×: Applicable
End Of Sie
DIAGNOSTIC TEST MODE (4WD)
A6E397018881203
Sending Emission-related Malfunction code (DTC) (Mode 03)
• The DTCs are shown in the table.
DTC table
×: Applicable
—: Not applicable
ON-BOARD DIAGNOSTIC
Component
Monitor item
Catalyst Misfire Fuel system Oxygen sensor
Oxygen sensor
heater
Input
CKP sensor ×××××
CMP sensor ×××××
VSS ×××
MAF sensor ×××××
ECT sensor ×××××
IAT sensor ××××
TP sensor ××××
Rear HO2S ×××
Front HO2S ××××
Output
DLC-2 ×××××
MIL ×××××
Purge solenoid valve ××
Fuel injectors ×
DTC No. Condition MIL DC Monitor item
Memory
function
P0010 CMP actuator circuit malfunction ON 1 CCM ×
P0011 CMP timing over-advanced ON 1 CCM ×
P0012 CMP timing over-retarded ON 1 CCM ×
P0031 Front HO2S heater circuit low input ON 2
O
2
sensor heater
×
P0032 Front HO2S heater circuit high input ON 2
O
2
sensor heater
×
P0037 Rear HO2S heater circuit low input ON 2
O
2
sensor heater
×
P0038 Rear HO2S heater circuit high input ON 2
O
2
sensor heater
×
P0101 MAF sensor inconsistent with TP sensor ON 2 CCM ×
P0102 MAF circuit low input ON 1 CCM ×
P0103 MAF circuit high input ON 1 CCM ×
P0107 MAP sensor circuit low input ON 1 CCM ×
P0108 MAP sensor circuit high input ON 1 CCM ×
P0111 IAT circuit performance problem ON 2 CCM ×
