E–4
COOLING SYSTEM
STRUCTURAL VIEW
A6E363002000201
MZR-CD (RF Turbo)
.
End Of Sie
COOLING SYSTEM
8
7
5
4
3
1
2
6
10
11
11
9
13
12
A6E3602W201
1 To water heater system
2 Radiator
3 Coolant reservoir tank
4Thermostat
5 Water pump
6 Cylinder head
7 Cylinder block
8 Engine oil cooler
9EGR water cooler
10 To cylinder head
11 To cylinder block
12 Turbocharger
13 Water outlet
