H–2
OUTLINE
OUTLINE OF CONSTRUCTION
A6E490216003201
• The construction and operation of the clutch is essentially carried over from that of the current MPV (LW)
models, except for the following features. (See Mazda MPV Training Manual 3340-1*-99F.)
End Of Sie
FEATURES
A6E490216003202
Adoption of the A65M-R manual transaxle models
• The specifications for the A65M-R manual transaxle models have been added.
Increased torque transmission capacity
• Increased clutch cover set load.
Reduced noise
• The flywheel with a damper has been adopted for the A65M-R manual transaxle model.
End Of Sie
SPECIFICATIONS
A6E490216003203
Bold frames:New specifications
End Of Sie
SUPPLEMENTAL SERVICE INFORMATION
A6E490216003204
• The following changes have been made since publication of the Mazda6 Workshop Manual (1730-1*-02C).
CLUTCH RELEASE CYLINDER
• Removal/installation procedure has been modified.
• Disassembly/assembly procedure has been modified.
CLUTCH UNIT
• Removal/installation procedure has been modified.
• Clutch cover inspection procedure has been modified.
FLYWHEEL
• Flywheel inspection procedure has been modified.
End Of Sie
OUTLINE
Item New Mazda6 (GG, GY) Current MPV (LW)
Engine MZR-CD (RF Turbo)
Manual transaxle type A65M-R
Clutch control Hydraulic
Clutch cover
Spring type Diaphragm
Set load (N {kgf, lbf}) 6,550 {668, 1,472}
Clutch disc
Outer diameter (mm {in}) 239 {9.41}
Inner diameter (mm {in}) 160 {6.30}
Clutch pedal
Type Suspended
Pedal ratio 5.9 6.41
Full stroke (mm {in}) 140 {5.51} 148 {5.83}
Clutch master cylinder inner diameter (mm {in}) 15.87 {0.625}
Clutch release cylinder inner diameter (mm {in}) 19.05 {0.750}
Clutch fluid type SAE J1703, FMVSS116 DOT-3 or DOT-4
OUTLINE
