Mazda Mazda6 - Structural View

INTAKE-AIR SYSTEM
F2–9
F2
STRUCTURAL VIEW
A6E401001005202
.
9
8
7
5
4
3
10
14
13
11
12
6
1
2
15
16
14
A6E40102029
1 Glow plug
2 Intake manifold
3 VSC valve actuator
4 Charge air cooler
5 Vacuum damper
6 Glow plug lead
7 Guide blade actuator
8 Turbocharger
9 VSC solenoid valve
10 VBC solenoid valve
11 VBC check valve
12 Air cleaner
13 Glow plug relay
14 Accelerator pedal component
15 L.H.D.
16 R.H.D.
