LOCATION INDEX
M–19
M
AXLE/DRIVE SHAFT LOCATION INDEX
A6E630025500201
.
End Of Sie
LOCATION INDEX
5
4
3
1
2
A6J63002001
1 Wheel hub bolt
(See M–22 WHEEL HUB BOLT REPLACEMENT)
2 Wheel hub, knuckle
(See M–22 WHEEL HUB, KNUCKLE REMOVAL/
INSTALLATION)
3 Joint shaft
(See M–29 JOINT SHAFT (MZR-CD (RF Turbo))
DISASSEMBLY/ASSEMBLY)
(See M–31 JOINT SHAFT (4WD) DISASSEMBLY/
ASSEMBLY)
4 Front drive shaft
(See M–34 FRONT DRIVE SHAFT (MZR-CD (RF
Turbo)) DISASSEMBLY/ASSEMBLY)
(See M–39 FRONT DRIVE SHAFT (4WD)
DISASSEMBLY/ASSEMBLY)
5 Rear drive shaft
(See M–42 REAR DRIVE SHAFT
PRE-INSPECTION)
(See M–43 REAR DRIVE SHAFT REMOVAL/
INSTALLATION)
(See M–45 REAR DRIVE SHAFT DISASSEMBLY/
ASSEMBLY)
