D–6
OUTLINE, LUBRICATION SYSTEM
SUPPLEMENTAL SERVICE INFORMATION
A6E330202000204
• The following changes and/or additions have been made since publication of the Mazda6 Workshop Manual
(1730-1*-02C).
Oil pressure
• Inspection procedure has been adopted. (MZR-CD (RF Turbo) engine model)
Engine oil
• Inspection procedure has been adopted. (MZR-CD (RF Turbo) engine model)
• Replacement procedure has been adopted. (MZR-CD (RF Turbo) engine model)
Oil filter
• Replacement procedure has been adopted. (MZR-CD (RF Turbo) engine model)
Oil cooler
• Removal/Installation procedure has been adopted. (MZR-CD (RF Turbo) engine model)
Oil pan
• Removal/Installation procedure has been adopted. (MZR-CD (RF Turbo) engine model)
End Of Sie
LOCATION INDEX
A6E333014100201
MZR-CD (RF Turbo)
.
End Of Sie
OUTLINE
LUBRICATION SYSTEM
4
3
1
2
A6E3300W003
1 Oil pressure switch
(See D–7 OIL PRESSURE INSPECTION)
2 Oil filter
(See D–9 OIL FILTER REPLACEMENT)
3 Oil cooler
(See D–9 OIL COOLER REMOVAL/
INSTALLATION)
4 Oil pan
(See D–10 OIL PAN REMOVAL/INSTALLATION)
To Next Page
