CLUTCH RELEASE CYLINDER
H–3
H
CLUTCH RELEASE CYLINDER REMOVAL/INSTALLATION (A65M-R MANUAL TRANSAXLE MODELS)
A6E491841920201
1. Remove the under cover.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
.
End Of Sie
CLUTCH RELEASE CYLINDER
12.7—21.6 N·m
{130—220 kgf·cm,
113—190 in·lbf}
18.6—25.5 {1.90—2.60,13.8—18.8}
N
.
m {kgf
.
m,ft
.
lbf}
3
GREASE
2
1
SST
*
*
49 0259 770B
(MOLYBDENUM SULFIDE)
A6E4918W010
1 Clutch pipe
2Bolt
3 Clutch release cylinder
