G–2
OUTLINE
OUTLINE OF CONSTRUCTION
A6E470202000201
• The construction and operation of the engine electrical system for the new Mazda6 (GG, GY) MZR-CD (RF
Turbo) engine model is the same as the current Mazda 323 (BJ) RF engine model. (European specs.) (See
Mazda 323 Training Manual 3324-10-98E.)
• The construction and operation of the engine electrical system for the new Mazda6 (GG, GY) L8, LF, and L3
engine models is the same as the current Mazda6 (GG) L8, LF, and L3 engine models. (See Mazda6 Training
Manual 3359-1*-02C, Mazda6 Workshop Manual 1730-1*-02C.)
End Of Sie
SPECIFICATIONS
A6E470202000203
Gasoline engine
* : Cold area or intensely hot area
Diesel engine
Bold frames:New specifications
* : Cold area
End Of Sie
OUTLINE
Item
Specification
New
Mazda6
(GG, GY)
Current
Mazda6
(GG)
New
Mazda6
(GG, GY)
Current
Mazda6
(GG)
New
Mazda6
(GG, GY)
Current
Mazda6
(GG)
L8 LF L3
Battery
Type and capacity
(5-hour rate)
50D20L (40),
75D26L (52)
*
50D20L (40),
75D26L (52)
*
50D20L (40),
80D26L (55)
*
Voltage (V) 12
Generator
Output (V-A) 12-90
Regulated voltage
Controlled by PCM
Self-diagnosis
function
Ignition
system
Type DEI (Double Electronic Ignition)
Spark advance Electronic
Firing order 1—3—4—2
Spark
plug
Type NGK ITR6F-13
Starter
Type Coaxial reduction
Output (kW) 1.0 1.4
Item
Specification
New Mazda6 (GG, GY) Current Mazda 323 (BJ)
MZR-CD (RF Turbo) RF
Battery
Type and capacity
(5-hour rate)
95D31L (64),
115D31L (70)
*
Voltage (V) 12
Generator
Output (V-A) 12-90 12-80
Regulated voltage 14.1—14.7
Self-diagnosis function Equipped
Starter
Type Coaxial reduction
Output (kW) 2.2
