Mazda Mazda6 - Emission System; Outline

F2–14
EMISSION SYSTEM
OUTLINE
A6E401601007201
• The emission system is essentially carried over from that of the current MPV (LW) MZR-CD (RF Turbo) engine
model. (See MPV Workshop Manual Supplement 1737-1*-02D.)
×:Applicable
End Of Sie
EMISSION SYSTEM
Item
Mazda6
(GG,GY)
Current
MPV (LW)
Remark for new model
MZR-CD (RF Turbo)
Rollover valve ×
Same function as MPV (LW) MZR-CD (RF Turbo) engine model
Shape has been changed
Check valve (two-way) ×
Same function as MPV (LW) MZR-CD (RF Turbo) engine model
Shape has been changed
Intake shutter valve actuator × Same function as MPV (LW) MZR-CD (RF Turbo) engine model
Intake shutter solenoid valve
(half) (full)
× Same function as MPV (LW) MZR-CD (RF Turbo) engine model
EGR valve × Same function as MPV (LW) MZR-CD (RF Turbo) engine model
EGR solenoid valve (vacuum)
(vent)
× Same function as MPV (LW) MZR-CD (RF Turbo) engine model
EGR control solenoid valve × Same function as MPV (LW) MZR-CD (RF Turbo) engine model
EGR water cooler × Same function as MPV (LW) MZR-CD (RF Turbo) engine model
Warm up oxidation catalytic
converter
× Same function as MPV (LW) MZR-CD (RF Turbo) engine model
Oxidation catalytic converter × Same function as MPV (LW) MZR-CD (RF Turbo) engine model
