CONTROL SYSTEM, ON-BOARD DIAGNOSTIC
CONTROLLER AREA NETWORK (CAN)
A6E404018881206
Outline
• The PCM transmit/received the information other units using CAN to simplify the system.
Transmit Information
• Engine speed
• Vehicle speed
• Accelerator pedal position
• Fuel injection information
• Torque reduction inhibit
• Intake air temperature
• Engine coolant temperature
• Travelled distance
• Glow indicator light conditions
• Engine displacement
• Number of cylinders
• Air induction type
• Fuel type and delivery
• Country
• Transmission/axle type
• Tire circumference (front/rear)
• Cruise main indicator light conditions
• Cruise set indicator light conditions
Received Information
• Torque reduction request from DSC HU/CM
• Wheel speed from ABS HU/CM or DSC HU/CM
— Front left
— Front right
• Travelled distance from ABS HU/CM or DSC HU/CM
End Of Sie
OUTLINE
A6E407018881201
• The on-board diagnostic system is essentially carried over from that of the current MPV (LW) MZR-CD (RF
Turbo) engine models, except for the following. (See MPV Workshop Manual Supplement 1737-1*-02C.)
— DTCs, PID monitoring items, and simulation items have been changed.
— KOEO/KOER self-test items have been changed.
End Of Sie
DTC
A6E407018881202
×: Applicable –: Not applicable
ON-BOARD DIAGNOSTIC
DTC Condition Detection condition MIL
Memory
function
P0016
Crankshaft position-camshaft position
correlation malfunction
Input signals from CKP sensor and CMP sensor
are misaligned.
××
P0088 Fuel pressure system too high
Fuel pressure is higher than preprogrammed
criteria.
– ×
P0091 Suction control valve circuit low input
Input voltage from suction control valve does not
change from off to on.
××
P0092 Suction control valve circuit high input
Input voltage from suction control valve does not
change from on to off.
××
P0093 Fuel system leak detection
Fuel pressure after fuel injection is lower than
preprogrammed criteria.
××
P0097 IAT sensor No.1 circuit low input Input voltage from IAT sensor No.1 is below 0.1 V. ××
P0098 IAT sensor No.1 circuit high input Input voltage from IAT sensor No.1 is above 5.0 V. ××
P0102 MAF sensor circuit low input Input voltage from MAF sensor is below 0.2 V. ××
P0103 MAF sensor circuit high input Input voltage from MAF sensor is above 4.9 V. ××
P0107 Boost sensor circuit low input
Input voltage from boost sensor is below 1.9 V
when engine speed is 2,400 rpm or above and
accelerator opening angle is 50% or above.
××
P0108 Boost sensor circuit high input Input voltage from boost sensor is above 4.9 V. ××
