AUTOMATIC TRANSAXLE
A6E931001024203
End Of Sie
PROPELLER SHAFT
A6E931001024204
End Of Sie
Item Specification
Transaxle type JA5AX-EL
Line pressure
(kPa {kgf/cm
2
, psi})
D range, M range (2GR)
Idle 290—490 {3.0—5.0, 42—71}
Stall 1,550—1,750 {15.8—17.8, 225—254}
M range (1GR), R position
Idle 550—750 {5.6—7.6, 80—109}
Stall 1,550—1,750 {15.8—17.8, 225—254}
Engine stall speed
D, M (1GR, 2GR), R 2,200—2,600
(rpm)
Time lag (second)
N-D Approx. 0.5—1.0
N-R Approx. 0.6—1.0
Transaxle fluid
temperature (TFT)
sensor
-20 °C {−4 °F} 15.87—17.54
0 °C {32 °F} 5.73—6.33
20 °C {68 °F} 2.38—2.63
40 °C {104 °F} 1.10—1.22
60 °C {140 °F} 0.56—0.62
80 °C {176 °F} 0.31—0.34
(kilohm) 100 °C {212 °F} 0.18—0.20
120 °C {248 °F} 0.11—0.12
130 °C {266 °F} 0.09—0.10
Input/turbine
speed sensor
(ohm) ATF temperature: 20 °C {68 °F} 513—627
Intermediate
sensor
(ohm) ATF temperature: 20 °C {68 °F} 513—627
Vehicle
speedometer
sensor
(ohm) ATF temperature: 20 °C {68 °F} 513—627
Solenoid valves (ohm)
Shift solenoid A 14—18
Shift solenoid B 14—18
Shift solenoid C 14—18
Neutral shift solenoid valve 14—18
Reduction timing solenoid valve 14—18
TCC solenoid valve 12.0—13.2
2-4 brake solenoid valve 2.6—3.2
High clutch solenoid valve 2.6—3.2
Pressure control solenoid 2.6—3.2
Automatic transaxle fluid
(ATF)
Type
M-
III
or equivalent (e.g. Dexron
®
III
)
Capacity (Approximate quantity) (L {US qt, Imp qt}) 8.3 {8.8, 7.3}
Transfer oil
Grade API service GL-5
Viscosity SAE 80W-90
Capacity (Approximate quantity) (L {US qt, Imp qt}) 0.62 {0.65, 0.54}
Item Specification
Runout limit mm {in} 0.3 {0.01}
Starting torque
N·m
{kgf·cm}
0.29—0.78 {3.0—7.9}
