Mazda Mazda6 - Selector Lever Disassembly;Assembly

K2–122
AUTOMATIC TRANSAXLE SHIFT MECHANISM
SELECTOR LEVER DISASSEMBLY/ASSEMBLY
A6E571646102203
1. Disassemble in the order shown in the figure.
2. Assemble in the reverse order of disassembly.
.
End Of Sie
3
A
A
2
1
4
A6E5716W106
1 Selector lever knob
2 Indicator panel
3 Selector illumination light
4 Selector lever
