Mazda Mazda6 - Front Drive Shaft

TD–6
TECHNICAL DATA
FRONT AND REAR AXLE
A6E931001018201
End Of Sie
STEERING SYSTEM
A6E931001034201
End Of Sie
Item Specification
FRONT DRIVE SHAFT
Shaft length
(Air in boot at atmospheric
pressure)
(mm {in})
Left side
MZR-CD (RF Turbo): 666.1—676.1 {26.23—26.61}
4WD: 667—677 {26.26—26.65}
Right side
MZR-CD (RF Turbo): 615.9—625.9 {24.25—24.64}
4WD: 631—641 {24.85—25.23}
REAR DRIVE SHAFT (4WD)
Shaft length
(Air in boot at atmospheric
pressure)
(mm {in})
Left side 805.4—815.4 {31.71—32.10}
Right side 852.4—862.4 {33.56—33.95}
REAR DIFFERENTIAL (4WD)
Pinion height (mm {in}) –0.025—0.025 {–0.001—0.001}
Backlash of side gear and differential pinion (mm {in}) 0.1 {0.004} or less
Drive pinion preload (N·m kgf·cm, in·lbf) 1.3—1.8 {13.3—18.3, 11.5—15.9}
Backlash of drive pinion and
ring gear
(mm {in})
Standard 0.09—0.11 {0.0036—0.0043}
Minimum 0.05 {0.002}
Differential oil
Grade API service GL-5
Viscosity
Above –18°C {0°F}: SAE 90
Below –18°C {0°F}: SAE 80
Capacity
(Approximate quantity)
(L {US qt, lmp qt}) 1.00 {1.06, 0.88}
ELECTRONIC 4WD CONTROL SYSTEM
Differential oil temperature
sensor
(kilohm)
0°C {32°F} 91—100
10°C {50°F} 56—61
20°C {68°F} 35—39
30°C {86°F} 23—25
40°C {104°F} 14—17
50°C {122°F} 10—11
60°C {140°F} 7.1—7.9
70°C {158°F} 5.0—5.6
80°C {176°F} 3.6—4.0
4WD solenoid
(Rear differential oil temperature
at 20°C {68°F})
(ohm) 1.5—2.0
Item Specification
ENGINE SPEED SENSING POWER STEERING
Power
steering oil
pump
Oil pump fluid pressure 2WD (Except MZR-CD (RF Turbo)):
10.80—11.29 {110.2—115.1, 1,567—1,637}
MZR-CD (RF Turbo):
11.31—11.80 {115.4—120.3, 1,641—1,711}
4WD: 10.30—10.79 {105.1—110.0, 1,490—1,564}
(MPa {kgf·cm
2
, psi})
Gear housing fluid pressure 2WD (Except MZR-CD (RF Turbo)):
10.80—11.29 {110.2—115.1, 1,567—1,637}
MZR-CD (RF Turbo):
11.31—11.80 {115.4—120.3, 1,641—1,711}
4WD: 10.30—10.79 {105.1—110.0, 1,490—1,564}
(MPa {kgf·cm
2
, psi})
Power
steering
system
Fluid type
ATF M-
III
or equivalent (e.g. Dexron
®
II
)
Capacity (Approximate quantity) MTX (Except MZR-CD (RF Turbo)): 0.80 {0.85, 0.70}
ATX (Except 4WD): 0.87 {0.92, 0.77}
MZR-CD (RF Turbo): 0.86 {0.91, 0.76}
4WD: 0.89 {0.94, 0.78}
(L {US qt, Imp qt})
