LOCATION INDEX
B2–3
B2
LOCATION INDEX
A6E230001002201
.
LOCATION INDEX
7
5
4
3
1
2
6
A6E2500W100
1
Drive belt
(See B2–4 DRIVE BELT INSPECTION)
(See B2–4 DRIVE BELT REPLACEMENT)
(See B2–4 DRIVE BELT AUTO TENSIONER
INSPECTION)
2 Rocker arm
(See B2–5 VALVE CLEARANCE INSPECTION)
(See B2–6 VALVE CLEARANCE ADJUSTMENT)
3 Engine
(See B2–8 COMPRESSION INSPECTION)
(See B2–27 ENGINE REMOVAL/INSTALLATION)
(See B2–32 ENGINE DISASSEMBLY/ASSEMBLY)
4 Timing Belt
(See B2–9 TIMING BELT REMOVAL/
INSTALLATION)
5 Cylinder head gasket
(See B2–15 CYLINDER HEAD GASKET
REPLACEMENT)
6 Front oil seal
(See B2–24 FRONT OIL SEAL REPLACEMENT)
7 Rear oil seal
(See B2–26 REAR OIL SEAL REPLACEMENT)
To Next Page
