K2–132
ON-BOARD DIAGNOSTIC
DTC P0711
A6E577018901207
Diagnostic procedure
End Of Sie
DTC P0711 Transaxle fluid temperature (TFT) sensor malfunction (stuck)
DETECTION
CONDITION
• TFT sensor signal stays outside normal temperature range for 10 minute or more.
Diagnostic support note:
• This is a continuous monitor (CCM).
• MIL illuminates if TCM detects the above malfunction conditions in two consecutive drive cycles.
• PENDING CODE is available.
• FREEZE FRAME DATA is available.
• AT warning light does not indication.
• DTC is stored in TCM memory.
POSSIBLE
CAUSE
• TFT sensor malfunction.
• Connector corrosion.
• TCM malfunction.
STEP INSPECTION ACTION
1 VERIFY FREEZE FRAME DATA HAS BEEN
RECORDED
• Has FREEZE FRAME PID DATA been
recorded?
Yes Go to next step.
No Record FREEZE FRAME PID DATA on repair order, then
go to next step.
2 VERIFY RELATED REPAIR INFORMATION
AVAILABILITY
• Check for related Service Bulletins and/or on-
line repair information availability.
• Is any related repair information available?
Yes Perform repair or diagnosis according to available repair
information.
• If vehicle is not repaired, go to next step.
No Go to next step.
3 INSPECT TFT SENSOR VOLTAGE
• Connect voltmeter to TCM terminal 1F.
• Turn ignition key to ON (engine OFF).
• Is TCM terminal voltage 1.55 V?
Yes Go to next step.
No Go to Step 6.
4 VERIFY CURRENT INPUT SIGNAL STATUS - IS
CONCERN INTERMITTENT OR CONSTANT?
• Start engine.
• Drive vehicle at 60 km/h {37 mph} or above
for 10 minutes or more.
— ATF 20 °C {68 °F}: 1.55 V
— ATF 60 °C {140 °F}: 0.7 V
• Does TCM terminal voltage change?
Yes Go to Step 6.
No Go to next step.
5 INSPECT TERMINAL CONDITION
• Turn ignition key to OFF.
• Disconnect terminal component No.2 (8-pin).
• Inspect terminals for corrosion.
• Are terminals okay?
Yes Replace TFT sensor, then go to next step.
No Repair or replace terminals, then go to next step.
6 VERIFY TROUBLESHOOTING OF DTC P0711
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Clear DTC from memory using WDS or
equivalent.
• Decrease ATF temperature to 20 °C {68 °F} or
below.
• Drive vehicle at 60 km/h {37 mph} or above
for 10 minutes or more.
• Is same DTC present?
Yes Replace TCM, then go to next step.
(See K2–96 TCM REMOVAL/INSTALLATION.)
No Go to next step.
7 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See K2–124 AFTER REPAIR PROCEDURE.)
• Is there any DTC present?
Yes Go to applicable DTC inspection.
No Troubleshooting completed.
