F1–2
OUTLINE
OUTLINE OF CONSTRUCTION
A6E390218881201
• The fuel and emission control systems are essentially carried over from the current Mazda6 (GG), except for
the following features. (See Mazda6 Training Manual 3359-1*-02C.)
End Of Sie
FEATURES
A6E390218881202
System simplification
• Controller area network has been adopted with TCM communication (4WD).
TCM adoption
• DTC for CAN (TCM communication) has been adopted.
Modifications to match the vehicle characteristics
• The idle speed has been modified.
• Fuel pump (transfer) has been adopted.
End Of Sie
SPECIFICATIONS
A6E390218881203
*
1
: Without the BARO sensor
*
2
: With the BARO sensor
Bold frames: New specifications
End Of Sie
OUTLINE
Item 2WD 4WD
Air cleaner element Type Paper element (oil permeated)
IAC valve Type Duty control
Fuel injector
Type Hi-ohmic
Type of fuel delivery Top-feed
Type of drive Voltage
Pressure regulator
Regulating pressure
(kPa {kgf/cm
2
, psi})
440 {4.5, 64}
Fuel tank
Capacity
(L {US qt, lmp qt})
64 {68, 56} 62 {65, 54}
Fuel Specification
Unleaded
(RON 90*
1
/95*
2
or above)
Unleaded (RON 95 or above)
Catalyst Type TWC (monolythic)
EGR control Type Stepping motor type
Evaporative emission control
system
Type Canister type
PCV system Type Closed type
To Next Page
