J2–6
MANUAL TRANSAXLE
REVERSE SWITCH REMOVAL/INSTALLATION
A6E521219010202
1. Remove the reverse switch.
2. Apply a light coat of silicone sealant to the screw
of the reverse switch.
Sealant
Three Bond product: TB1215
3. Install the reverse switch to the transaxle case.
Tightening torque
22.5—33.3 N·m
{2.29—3.40 kgf·m, 16.6—24.6 ft·lbf}
End Of Sie
NEUTRAL SWITCH INSPECTION
A6E521219010203
1. Disconnect the neutral switch connector.
2. Shift the shift lever to each position and neutral,
and inspect for continuity between the terminals A
and B.
• If not as specified, replace the neutral switch.
(See J2–7 NEUTRAL SWITCH REMOVAL/
INSTALLATION.)
3. Connect the neutral switch connector.
End Of Sie
REVERSE SWITCH
A6E5212W012
NEUTRAL
SWITCH
A6E5212W015
BA
NEUTRAL SWITCH
PART SIDE CONNENTOR
A6E5212W016
Shift position
Connector terminal
AB
:
Continuity
Neutral
Others
A6E5212W017
