F2–94
ON-BOARD DIAGNOSTIC
DTC P0093
A6E407001082205
Diagnostic procedure
End Of Sie
DTC P0093 Fuel system leak detection
DETECTION
CONDITION
• PCM monitors fuel pressure in common rail from fuel pressure sensor while engine running. If fuel pressure
is lower after fuel injection than preprogrammed criteria, PCM determines fuel system leak detection.
POSSIBLE
CAUSE
• Fuel leakage or clogged fuel line
• Suction control valve malfunction
• Fuel pressure sensor malfunction
• Fuel injector malfunction
• PCM malfunction
STEP INSPECTION ACTION
1 VERIFY RELATED REPAIR INFORMATION
AVAILABILITY
• Check for related Service Information
availability.
• Is any related repair information available?
Yes Perform repair or diagnosis according to available Service
Information.
• If vehicle is not repaired, go to next step.
No Go to next step.
2 FOLLOW OTHER DETECTED DTC FIRST
• Turn engine switch to OFF.
• Start engine.
• Have P0192, P0193, P1190 been detected?
Yes Go to applicable DTC inspection.
(See F2–87 DTC TABLE)
No Go to next step.
3 INSPECT FUEL LINE
• Turn engine switch to OFF.
• Inspect for fuel leakage or clogs in following
fuel lines for each cylinder:
— Supply pump and Common rail.
— Common rail and fuel injector.
• Is there any malfunction?
Yes Repair or replace suspected fuel line, go to Step 7.
No Go to next step.
4 INSPECT SUCTION CONTROL VALVE
• Inspect suction control valve.
(See F2–54 SUCTION CONTROL VALVE
INSPECTION)
• Is there any malfunction?
Yes Repair supply pump, go to Step 7.
(See F2–54 SUPPLY PUMP INSPECTION)
No Go to next step.
5 INSPECT FUEL PRESSURE SENSOR
• Inspect fuel pressure sensor.
(See F2–79 FUEL PRESSURE SENSOR
INSPECTION)
• Is there any malfunction?
Yes Replace common rail, go to Step 7.
(See F2–53 SUPPLY PUMP REMOVAL/INSTALLATION)
No Go to next step.
6 INSPECT FUEL INJECTOR
• Inspect fuel injector.
(See F2–56 FUEL INJECTOR INSPECTION)
• Is there any malfunction?
Yes Replace fuel injector, go to next step.
(See F2–55 FUEL INJECTOR REMOVAL/INSTALLATION)
No Go to next step.
7 VERIFY TROUBLESHOOTING OF DTC P0093
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Clear DTC from PCM memory using WDS or
equivalent.
• Start engine.
• Is same DTC present?
Yes Replace PCM, go to next step.
(See F2–64 PCM REMOVAL/INSTALLATION)
No Go to next step.
8 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See F2–86 AFTER REPAIR PROCEDURE)
• Is there any DTC present?
Yes Go to applicable DTC inspection.
(See F2–87 DTC TABLE)
No Troubleshooting completed.
