NO.25 ENGINE STALLS WHEN DRIVING AT SLOW SPEED OR STOPPING
A6E578001030228
Diagnostic procedure
End Of Sie
NO.26 STARTER DOES NOT WORK
A6E578001030229
End Of Sie
NO.27 GEAR POSITION INDICATOR LIGHT DOES NOT ILLUMINATE IN M RANGE
A6E578001030230
Diagnostic procedure
STEP INSPECTION ACTION
1 • Go to symptom troubleshooting No.4
“Engine stalls-after start/at idle”.
(See Section F.)
• Is engine control system okay?
Yes Go to next step.
No Repair or replace any defective parts according to
inspection results.
2 • Remove torque converter.
• Inspect torque converter.
(See ATX Workshop Manual.)
• Is torque converter okay?
Yes • Inspect for bend, damage or kinks of oil cooler line
pipes. If okay, overhaul control valve body and repair or
replace any defective parts.
(See ATX Workshop Manual.)
• If problem remains, replace or overhaul transaxle and
repair or replace any defective parts.
(See ATX Workshop Manual.)
No Replace torque converter.
3 • Verify test results.
— If okay, return to diagnostic index to service any additional symptoms.
— If malfunction remains, inspect related Service Informations and perform repair or diagnosis.
— If vehicle repaired, troubleshooting completed.
— If vehicle not repaired or additional diagnostic information not available, replace TCM.
25 Engine stalls when driving at slow speeds or stopping
DESCRIPTION • Engine stalls when brake pedal depressed while driving at low speed or stopping.
POSSIBLE
CAUSE
• Malfunction is on engine control side (e.g. Fuel injection control, IAC system)
Note
• Before following troubleshooting steps, make sure that Automatic Transaxle On-Board Diagnostic
and Automatic Transaxle Basic Inspection are conducted.
STEP INSPECTION ACTION
1 • Go to symptom troubleshooting No.10 “Low
idle/stalls during deceleration”.
(See Section F.)
• Is engine control system okay?
Yes Go to symptom troubleshooting No.24 “Engine stalls when
shifted to D range, or in R position”.
No Repair or replace any defective parts according to
inspection results.
2 • Verify test results.
— If okay, return to diagnostic index to service any additional symptoms.
— If malfunction remains, inspect related Service Informations and perform repair or diagnosis.
— If vehicle repaired, troubleshooting completed.
— If vehicle not repaired or additional diagnostic information not available, replace TCM.
26 Starter does not work
DESCRIPTION • Starter does not work even when P or N position.
POSSIBLE
CAUSE
• Selector lever misadjustment.
• TR switch misadjustment.
• Open or short circuit in TR switch.
27 Gear position indicator light does not illuminate in M range
DESCRIPTION
• Gear position indicator light in instrument cluster does not illuminate in M range and ignition switch at
on.
POSSIBLE
CAUSE
• M range switch, gear position indicator light or related wiring harness malfunction.
Note
• Before following troubleshooting steps, make sure that Automatic Transaxle On-Board Diagnostic
and Automatic Transaxle Basic Inspection are conducted.
STEP INSPECTION ACTION
1 • Are other indicator lights illuminated with
ignition switch on?
Yes Go to next step.
No Inspect meter fuse.
