CONTROL SYSTEM
F2–21
F2
End Of Sie
1PCM
2 Idle speed control
3Glow control
4 VSC
5 Boost pressure control
6 Fuel injection amount control
7 Fuel injection timing control
8 Multiple fuel injection control
9 Fuel pressure control
10 EGR control
11 Cruise control system
12 Electrical fan control
13 A/C cut-off control
14 Immobilizer system
15 Battery
16 Starter (starter signal)
17 Starter relay
18 Clutch switch
19 Neutral switch
20 Brake switch
21 Idle switch
22 A/C switch
23 Refrigerant pressure switch
24 Cruise control switch
25 Accelerator position sensor
26 MAF/IAT sensor
27 IAT sensor No.2
28 ECT sensor
29 Fuel temperature sensor
30 BARO sensor (integrated in PCM)
31 Boost sensor
32 Fuel pressure sensor
33 CMP sensor
34 CKP sensor
35 VSS
36 Calibration resistor
37 Immobilizer unit (integrated in PCM)
38 Suction control valve
39 IDM
40 VSC solenoid valve
41 VBC solenoid valve
42 EGR control solenoid valve
43 EGR solenoid valve (vacuum)
44 EGR solenoid valve (vent)
45 Intake shutter solenoid valve (half)
46 Intake shutter solenoid valve (full)
47 Glow indicator light
48 Cruise main indicator light
49 Cruise set indicator light
50 Glow plug relay
51 Cooling fan relay No.1
52 Cooling fan relay No.2
53 A/C relay
