B1–6
ENGINE
No.1 Engine Mount Rubber Removal Note
1. Suspend the engine using the SST.
2. Remove through-bolt A on the No.1 engine mount
bracket side.
3. Loosen through-bolt B on the front crossmember
side until approximately three pitches are
showing.
Note
• Do not remove the No.1 engine mount
rubber from the front crossmember.
No.4 Engine Mount Bracket and No.4 Engine Mount Rubber Removal Note
1. Secure the engine and the transaxle using an
engine jack and attachment as shown.
A6E2215W004
A
B
A6E2324W201
A6E2324W202
A6E2324W209
To Next Page
