F2130
ON-BOARD DIAGNOSTIC
End Of Sie
3 INSPECT POOR CONNECTION OF IDM
CONNECTOR
Turn engine switch to OFF.
Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 9.
No Go to next step.
4 INSPECT IDM CIRCUIT FOR SHORT TO GND
Turn engine switch to OFF.
Inspect continuity between following
harnesses:
IDM terminal 2B and body GND.
IDM terminal 2C and body GND.
IDM terminal 2D and body GND.
IDM terminal 2E and body GND.
IDM terminal 2F and body GND.
Is there continuity?
Yes Repair or replace harness for short to GND, go to Step 9.
No Go to next step.
5 INSPECT IDM CIRCUIT FOR SHORT TO
POWER
Turn engine switch to ON (Engine OFF).
Inspect voltage between following harnesses:
IDM terminal 2B and body GND.
IDM terminal 2C and body GND.
IDM terminal 2D and body GND.
IDM terminal 2E and body GND.
IDM terminal 2F and body GND.
Is voltage below 1.0 V?
Yes Go to next step.
No Repair or replace harness for short to power, go to Step 9.
6 INSPECT IDM
Inspect IDM.
(See F284 INJECTOR DRIVER MODULE
(IDM) INSPECTION)
Is there any malfunction?
Yes Replace IDM, go to Step 9.
No Go to next step.
7 INSPECT POOR CONNECTION OF PCM
CONNECTOR
Turn engine switch to OFF.
Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 9.
No Go to next step.
8 INSPECT IDM CIRCUIT FOR OPEN
Turn engine switch to OFF.
Inspect continuity between following
harnesses:
IDM terminal 2B and PCM terminal 30.
IDM terminal 2C and PCM terminal 42.
IDM terminal 2D and PCM terminal 44.
IDM terminal 2E and PCM terminal 45.
IDM terminal 2F and PCM terminal 43.
Is there continuity?
Yes Go to next step.
No Repair or replace harness for open, go to next step.
9 VERIFY TROUBLESHOOTING OF DTC P0200
COMPLETED
Make sure to reconnect all disconnected
connectors.
Clear DTC from PCM memory using WDS or
equivalent.
Start engine.
Is same DTC present?
Yes Replace PCM, go to next step.
(See F264 PCM REMOVAL/INSTALLATION)
No Go to next step.
10 VERIFY AFTER REPAIR PROCEDURE
Perform After Repair Procedure.
(See F286 AFTER REPAIR PROCEDURE)
Is there any DTC present?
Yes Go to applicable DTC inspection.
(See F287 DTC TABLE)
No Troubleshooting completed.
