ON-BOARD DIAGNOSTIC
F2133
F2
End Of Sie
2 INSPECT POOR CONNECTION OF
ACCELERATOR POSITION SENSOR NO.2
CONNECTOR
Turn engine switch to OFF.
Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 8.
No Go to next step.
3 INSPECT ACCELERATOR POSITION SENSOR
NO.2 POWER CIRCUIT FOR OPEN
Turn engine switch to ON. (Engine OFF).
Inspect voltage at accelerator position sensor
terminal A (harness side).
Is voltage below 1.0 V?
Yes Repair or replace harness for open, go to Step 8.
No Go to next step.
4 INSPECT ACCELERATOR POSITION SENSOR
NO.2 SIGNAL CIRCUIT FOR SHORT TO GND
Turn engine switch to OFF.
Inspect continuity between accelerator position
sensor terminal C and body GND.
Is there continuity?
Yes Repair or replace harness for short to GND, go to Step 8.
No Go to next step.
5 INSPECT ACCELERATOR POSITION SENSOR
NO.2 CIRCUIT FOR SHORT WITH EACH OTHER
Turn engine switch to OFF.
Inspect continuity between accelerator position
sensor terminals C and D.
Is there continuity?
Yes Repair or replace harness for short with each other, go to
Step 8.
No Go to next step.
6 INSPECT ACCELERATOR POSITION SENSOR
NO.2
Inspect accelerator position sensor No.2.
(See F272 ACCELERATOR POSITION
SENSOR INSPECTION)
Is there any malfunction?
Yes Replace accelerator position sensor, go to Step 8.
(See F244 ACCELERATOR PEDAL COMPONENT
DISASSEMBLY/ASSEMBLY)
No Go to next step.
7 INSPECT POOR CONNECTION OF PCM
CONNECTOR
Turn engine switch to OFF.
Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
Is there any malfunction?
Yes Repair or replace suspected terminal, go to next step.
No Go to next step.
8 VERIFY TROUBLESHOOTING OF DTC P0222
COMPLETED
Make sure to reconnect all disconnected
connectors.
Clear DTC from PCM memory using WDS or
equivalent.
Perform KOEO/KOER self-test.
(See F286 KOEO/KOER SELF-TEST
PROCEDURE)
Is same DTC present?
Yes Replace PCM, go to next step.
(See F264 PCM REMOVAL/INSTALLATION)
No Go to next step.
9 VERIFY AFTER REPAIR PROCEDURE
Perform After Repair Procedure.
(See F286 AFTER REPAIR PROCEDURE)
Is there any DTC present?
Yes Go to applicable DTC inspection.
(See F287 DTC TABLE)
No Troubleshooting completed.
STEP INSPECTION ACTION
