ON-BOARD DIAGNOSTIC
F2–135
F2
End Of Sie
2 INSPECT POOR CONNECTION OF
ACCELERATOR POSITION SENSOR NO.2
CONNECTOR
• Turn engine switch to OFF.
• Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
• Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 7.
No Go to next step.
3 INSPECT ACCELERATOR POSITION SENSOR
NO.2 CIRCUIT FOR SHORT WITH EACH OTHER
• Turn engine switch to OFF.
• Inspect continuity between accelerator position
sensor terminals A and C
• Is there continuity?
Yes Repair or replace harness for short with each other, go to
Step 7.
No Go to next step.
4 INSPECT ACCELERATOR POSITION SENSOR
NO.2
• Inspect accelerator position sensor No.2.
(See F2–72 ACCELERATOR POSITION
SENSOR INSPECTION)
• Is there any malfunction?
Yes Replace accelerator position sensor, go to Step 7.
(See F2–44 ACCELERATOR PEDAL COMPONENT
DISASSEMBLY/ASSEMBLY)
No Go to next step.
5 INSPECT POOR CONNECTION OF PCM
CONNECTOR
• Turn engine switch to OFF.
• Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
• Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 7.
No Go to next step.
6 INSPECT ACCELERATOR POSITION SENSOR
NO.2 CIRCUIT FOR OPEN
• Turn engine switch to OFF.
• Inspect continuity between following
harnesses:
— Accelerator position sensor terminal C and
PCM terminal 88.
— Accelerator position sensor terminal D and
PCM terminal 91.
• Is there continuity?
Yes Go to next step.
No Repair or replace harness for open, go to Step 7.
7 VERIFY TROUBLESHOOTING OF DTC P0223
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Clear DTC from PCM memory using WDS or
equivalent.
• Perform KOEO/KOER self-test.
(See F2–86 KOEO/KOER SELF-TEST
PROCEDURE)
• Is same DTC present?
Yes Replace PCM, go to next step.
(See F2–64 PCM REMOVAL/INSTALLATION)
No Go to next step.
8 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See F2–86 AFTER REPAIR PROCEDURE)
• Is there any DTC present?
Yes Go to applicable DTC inspection.
(See F2–87 DTC TABLE)
No Troubleshooting completed.
STEP INSPECTION ACTION
