ON-BOARD DIAGNOSTIC
F2–139
F2
End Of Sie
2 INSPECT POOR CONNECTION OF CKP
SENSOR CONNECTOR
• Turn engine switch to OFF.
• Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
• Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 7.
No Go to next step.
3 INSPECT CKP SENSOR CIRCUIT FOR SHORT
TO GND
• Turn engine switch to OFF.
• Inspect continuity between following
harnesses:
— CKP sensor terminal A and body GND.
— CKP sensor terminal B and body GND.
• Is there continuity?
Yes Repair or replace harness for short to GND, go to Step 7.
No Go to next step.
4 INSPECT CKP SENSOR
• Inspect CKP sensor.
(See F2–82 CRANKSHAFT POSITION (CKP)
SENSOR INSPECTION)
• Is there any malfunction?
Yes Replace CKP sensor, go to Step 7.
(See F2–81 CRANKSHAFT POSITION (CKP) SENSOR
REMOVAL/INSTALLATION)
No Go to next step.
5 INSPECT POOR CONNECTION OF PCM
CONNECTOR
• Turn engine switch to OFF.
• Inspect for poor connection (damaged, pulled-
out terminals, corrosion, etc.).
• Is there any malfunction?
Yes Repair or replace suspected terminal, go to Step 7.
No Go to next step.
6 INSPECT CKP SENSOR CIRCUIT FOR OPEN
• Turn engine switch to OFF.
• Inspect continuity between following
harnesses:
— CKP sensor terminal A and PCM terminal
29.
— CKP sensor terminal B and PCM terminal 3.
• Is there continuity?
Yes Go to next step.
No Repair or replace harness for open, go to next step.
7 VERIFY TROUBLESHOOTING OF DTC P0337
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Clear DTC from PCM memory using WDS or
equivalent.
• Start engine.
• Is same DTC present?
Yes Replace PCM, go to next step.
(See F2–64 PCM REMOVAL/INSTALLATION)
No Go to next step.
8 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See F2–86 AFTER REPAIR PROCEDURE)
• Is there any DTC present?
Yes Go to applicable DTC inspection.
(See F2–87 DTC TABLE)
No Troubleshooting completed.
STEP INSPECTION ACTION
