TROUBLESHOOTING
F2–187
F2
3 Connect WDS or equivalent to DLC-2.
Turn engine switch to ON.
Retrieve any DTC.
Is DTC displayed?
Yes DTC is displayed:
Go to appropriate DTC test.
Communication error message is displayed:
Inspect for following:
• Open circuit between PCM control relay and PCM
terminal 53 or 79
• Open circuit PCM control relay and PCM terminal
69
• PCM control relay stuck open
• Open or poor GND circuit (PCM terminal 65, 85,
103 or 104)
• Poor connection vehicle body GND
No No DTC is displayed:
Go to next step.
4 Note
• The following test should be performed on
the vehicles with A/C system. If the
following test cannot be performed due to
engine stalling, go to next step.
• Go to next step for the vehicle without A/C
system.
Connect pressure gauge to A/C line.
Turn blower and A/C switches on.
Is pressure within specifications?
Yes Go to next step.
No A/C is always on:
Go to symptom troubleshooting “NO.24 A/C ALWAYS
ON OR A/C COMPRESSOR RUNS
CONTINUOUSLY”.
Other symptoms:
Inspect for following:
• Refrigerant charging amount
• Cooling fan No.1 and/or cooling fan No.2 operation
5 Depress accelerator pedal slightly.
Crank engine.
Does engine start now?
Yes Inspect idle speed.
(See F2–34 IDLE SPEED INSPECTION)
No Go to next step.
6 Inspect adjustment of accelerator position
sensor and idle switch.
(See F2–72 ACCELERATOR POSITION
SENSOR INSPECTION)
(See F2–70 IDLE SWITCH INSPECTION)
Are accelerator position sensor and idle switch
adjusted correctly?
Yes Go to next step.
No Adjust accelerator position sensor and idle switch
correctly.
(See F2–73 ACCELERATOR POSITION SENSOR
ADJUSTMENT)
(See F2–71 IDLE SWITCH ADJUSTMENT)
7 Inspect for fuel leakage from fuel pipe.
Is any fuel leakage found on fuel pipe?
Yes Repair or replace as necessary.
No Go to next step.
8 Visually inspect CKP sensor and teeth of pulse
wheel.
Are CKP sensor and teeth of pulse wheel okay?
Yes Go to next step.
No Replace malfunctioning parts.
9 Measure gap between CKP sensor and teeth of
pulse wheel.
Specification
1.5—2.5 mm {0.059—0.098 in}
Is gap within specification?
Yes Go to next step.
No Adjust CKP sensor position.
10 Visually inspect CMP sensor and teeth of pulse
wheel.
Are CMP sensor and teeth of pulse wheel okay?
Yes Inspect following PIDs:
(See F2–65 PCM INSPECTION)
• ECT
• IAT
• MAF
• RPM
If PID value is not as specified, repair or replace
malfunctioning parts.
If PID value is okay, go to next step.
No Replace malfunctioning parts.
11 Inspect fuel pressure sensor.
(See F2–79 FUEL PRESSURE SENSOR
INSPECTION)
Is fuel pressure okay?
Yes Go to next step.
No Replace common rail.
12 Inspect suction control valve.
(See F2–54 SUCTION CONTROL VALVE
INSPECTION)
Is suction control valve okay?
Yes Go to next step.
No Repair supply pump.
(See F2–54 SUPPLY PUMP INSPECTION)
STEP INSPECTION RESULTS ACTION
