F2–214
TROUBLESHOOTING
5 Inspect intake shutter valve and VSC valve
operations.
(See F2–229 ENGINE CONTROL SYSTEM
OPERATION INSPECTION)
Is there any problem?
Yes Repair or replace as necessary.
No Go to next step.
6 Inspect guide blade valve operation.
(See F2–229 ENGINE CONTROL SYSTEM
OPERATION INSPECTION)
Is there any problem?
Yes Repair or replace as necessary.
No Go to next step.
7 Visually inspect CKP sensor and teeth of pulse
wheel.
Are CKP sensor and teeth of pulse wheel okay?
Yes Go to next step.
No Replace malfunctioning parts.
8 Measure gap between CKP sensor and teeth of
pulse wheel.
Specification
1.5—2.5 mm {0.059—0.098 in}
Is gap within specification?
Yes Go to next step.
No Adjust CKP sensor position.
9 Visually inspect CMP sensor and teeth of pulse
wheel.
Are CMP sensor and teeth of pulse wheel okay?
Yes Inspect following PIDs:
(See F2–65 PCM INSPECTION)
• IAT
• MAP
• RPM
If PID value is not as specified, repair or replace
malfunctioning parts.
If PID value is okay, go to next step.
No Replace malfunctioning parts.
10 Perform EGR system inspection.
Is EGR system okay?
Yes Go to next step.
No Repair or replace malfunctioning part according to
EGR system operation results.
11 Inspect VSC system operation.
Does VSC system operate properly?
Yes Go to next step.
No Repair or replace malfunctioning part according to
VSC system operation inspection results.
12 Inspect hose bands between following parts:
• Turbocharger compressor housing and air
cleaner
• Turbocharger compressor housing and
charge air cooler
Are hose bands loose?
Yes Retighten hose bands.
If concern is resolved, complete inspection.
If concern still exists, go to next step.
No Go to next step.
13 Inspect for improper operation, kinks, clogging or
disconnection on guide blade actuator.
(See F2–229 ENGINE CONTROL SYSTEM
OPERATION INSPECTION)
Is actuator okay?
Yes Go to next step.
No Repair or replace as necessary.
If concern is resolved, complete inspection.
If concern still exists, turbocharger is okay.
Go to next step.
14 Remove parts necessary to inspect
turbocharger.
Do not remove turbocharger.
Inspect if turbocharger compressor wheel is
bent, damaged, or interfering with housing on
vehicle.
Is there any problem?
Yes Replace turbocharger.
No Go to next step.
STEP INSPECTION RESULTS ACTION
