B2–14
TIMING BELT
Crankshaft Pulley Installation Note
1. Tighten the bolts in the order shown.
Tightening torque
23—32 N·m {2.3—3.3 kgf·m, 17—23 ft·lbf}
No.3 Engine Joint Bracket Installation Note
1. Tighten the No.3 engine joint bracket bolt and nut
in the order shown.
Tightening torque
74.5—104.9 N·m {7.6—10.6 kgf·m,
55.0—76.6 ft·lbf}
7
5
4
3
6
1
2
A6E2316W110
1
2
A6E2316W111
