AUTOMATIC TRANSAXLE
K2–89
K2
Resistance Inspection (Off-Vehicle)
1. Remove each solenoid valve. (See K2–90 SOLENOID VALVE REMOVAL/INSTALLATION.)
2. Measure the resistance of each solenoid valve individually.
• If not specified, replace the solenoid valve.
• If it is normal, replace the harness.
Pressure control solenoid, 2-4 brake solenoid valve, and high clutch solenoid valve
Resistance: 2.6—3.2 ohms (20 °C {68 °F})
Shift solenoid A, B, C, neutral shift solenoid valve, and reduction timing solenoid valve
Resistance: 14—18 ohms (20 °C {68 °F})
TCC solenoid valve
Resistance: 12—13.2 ohms (20 °C {68 °F})
3. Install each solenoid valve. (See K2–90
SOLENOID VALVE REMOVAL/INSTALLATION.)
End Of Sie
AMU0517W034
AMU0517W035
AMU0517W036
