CYLINDER HEAD GASKET
B2–23
B2
Supply Pump Pulley Installation Note
Caution
• To prevent the bolts (M8 x1.25) from damaging the supply pump and pulley, do not fully tighten
the fixing bolts. If they contact the pulley surface, they will damage the pulley.
1. Fix the supply pump pulley to the bracket using
two bolts (M8 x 1.25).
End Of Sie
M8 1.25
BOLT
A6E2318W101
