ON-BOARD DIAGNOSTIC
K2–145
K2
Diagnostic procedure
STEP INSPECTION ACTION
1 VERIFY FREEZE FRAME DATA HAS BEEN
RECORDED
• Has FREEZE FRAME PID DATA been
recorded?
Yes Go to next step.
No Record FREEZE FRAME PID DATA on repair order, then
go to next step.
2 VERIFY RELATED REPAIR INFORMATION
AVAILABILITY
• Check for related Service Bulletins and/or on-
line repair information availability.
• Is any related repair information available?
Yes Perform repair or diagnosis according to available repair
information.
• If vehicle is not repaired, go to next step.
No Go to next step.
3 INSPECT TERMINAL COMPONENT NO.1 (12-
PIN) FOR POOR CONNECTION
• Turn ignition key to OFF.
• Disconnect terminal componentNo.1 (12-pin).
• Check for poor connection (damaged, pulled-
out, terminals, corrosion, etc.).
• Are terminals okay?
Yes Go to next step.
No Repair or replace terminals, then go to Step 13.
4 INSPECT RESISTANCE
• Check resistance between terminal component
No.1 (12-pin) terminal H (transaxle case side)
and body ground.
• Is resistance within 12—13.2 ohms?
(See K2–88 SOLENOID VALVE INSPECTION.)
Yes Go to Step 9.
No Go to next step.
5 INSPECT COUPLER COMPONENT (10-PIN)
FOR POOR CONNECTION
• Disconnect coupler component (10-pin)
connector.
• Check for poor connection (damaged, pulled-
out, terminals, corrosion, etc.).
• Is terminal okay?
Yes Go to next step.
No Repair or replace terminal, then go to Step 13.
6 INSPECT RESISTANCE
• Check resistance between coupler component
(10-pin) terminal C (part side) and body
ground.
• Is resistance within 12—13.2 ohms?
(See K2–88 SOLENOID VALVE INSPECTION.)
Yes Repair or replace terminal component No.1 (12-pin), then
go to Step 13.
No Go to next step.
7 INSPECT TCC SOLENOID VALVE
CONNECTOR FOR POOR CONNECTION
• Disconnect TCC solenoid valve connector.
• Check for poor connection (damaged, pulled-
out, terminals, corrosion, etc.).
• Is terminal okay?
Yes Go to next step.
No Repair or replace terminal, then go to Step 13.
8 INSPECT RESISTANCE
• Check resistance between TCC solenoid valve
connector (part side) terminal A and body
ground.
• Is resistance within 12—13.2 ohms?
(See K2–88 SOLENOID VALVE INSPECTION.)
Yes Repair or replace coupler component (10-pin), then go to
Step 13.
No Verify TCC solenoid valve installation.
• If TCC solenoid valve is installed correctly, replace TCC
solenoid valve, then go to Step 13.
(See K2–90 SOLENOID VALVE REMOVAL/
INSTALLATION.)
9 INSPECT TCM CONNECTOR FOR POOR
CONNECTION
• Disconnect TCM connector.
• Check for poor connection (damaged, pulled-
out, terminals, corrosion, etc.).
• Are terminals okay?
Yes Go to next step.
No Repair terminals, then go to Step 13.
10 INSPECT TERMINAL COMPONENT NO.1 (12-
PIN) CIRCUIT FOR OPEN CIRCUIT
• Check continuity between TCM terminal 2S
(harness-side) and terminal component No.1
(12-pin) terminal H (harness-side).
• Is there continuity between terminals?
Yes Go to next step.
No Repair or replace harness, then go to Step 13.
To Next Page
