11 INSPECT TCM CIRCUIT FOR SHORT TO
GROUND
• Turn ignition key to OFF.
• Check continuity between TCM terminal 2U
(harness-side) and body ground.
• Is there any continuity?
Yes Repair or replace harness, then go to next step.
No Go to next step.
12 VERIFY TROUBLESHOOTING OF DTC P0798
COMPLETED
• Make sure to reconnect all disconnected
connectors.
• Clear DTC from memory using WDS or
equivalent.
• Drive vehicle in D range and make sure that
gears shift smoothly from 1GR to 5GR.
• Is same DTC present?
Yes Replace TCM, then go to next step.
(See K2–96 TCM REMOVAL/INSTALLATION.)
No Go to next step.
13 VERIFY AFTER REPAIR PROCEDURE
• Perform “After Repair Procedure”.
(See K2–124 AFTER REPAIR PROCEDURE.)
• Is there any DTC present?
Yes Go to applicable DTC inspection.
No Troubleshooting completed.
