ON-BOARD DIAGNOSTIC
K2–181
K2
End Of Sie
SSB/SS2
(Shift solenoid
B)
ON/OFF
N position: ON
D range 4GR: OFF
Inspect shift solenoid B.
(See K2–88 SOLENOID VALVE
INSPECTION.)
–
SSC/SS3
(Shift solenoid
C)
ON/OFF
N position: ON
D range 2GR: OFF
Inspect shift solenoid C.
(See K2–88 SOLENOID VALVE
INSPECTION.)
–
TCCC
(TCC solenoid
valve)
%
TCC operating: ON
TCC non operating: OFF
Inspect TCC solenoid valve.
(See K2–88 SOLENOID VALVE
INSPECTION.)
2S
TFT
(ATF
temperature)
°C
ATF 20 °C {68 °F}: 20 °C {68 °F}
ATF 60 °C {140 °F}: 60 °C {140 °F}
Inspect TFT sensor.
(See K2–84 TRANSAXLE FLUID
TEMPERATURE (TFT) SENSOR
INSPECTION.)
1B, 1F
TFTV
(ATF
temperature
signal voltage)
V
ATF 20 °C {68 °F}: 1.55 V
ATF 60°C {140 °F}: 0.7 V
Inspect TFT sensor.
(See K2–84 TRANSAXLE FLUID
TEMPERATURE (TFT) SENSOR
INSPECTION.)
1B, 1F
THOP
(Throttle
position)
%
CTP:0%
WOT: 100%
Inspect TCM.
(See K2–90 TCM INSPECTION.) –
TRD
(TR switch [D
range])
ON/OFF
D range: ON
Other ranges and all positions: OFF
Inspect TR switch.
(See K2–80 TRANSAXLE RANGE (TR)
SWITCH INSPECTION.)
1Z
TRR
(TR switch [R
position])
ON/OFF
R position: ON
Other positions and all ranges: OFF
Inspect TR switch.
(See K2–80 TRANSAXLE RANGE (TR)
SWITCH INSPECTION.)
1W
TSS
(Input/turbine
speed sensor)
rpm
Ignition switch ON: 0 rpm
Idle: 700—800 rpm
Inspect input/turbine speed sensor.
(See K2–85 INPUT/TURBINE SPEED
SENSOR INSPECTION.)
1N, 2F
UP_SW
(Up switch)
ON/OFF
Up sift at M range: ON
Other: OFF
Inspect selector lever component.
2C
VPWR
(Battery
voltage)
V
IG ON: B+
Idle: 13—14 V
Inspect main relay.
1P
VSS
(Vehicle
speed)
km/h
Vehicle speed 20 km/h {12.5 mph}: 20
km/h {12.5 mph}
Vehicle speed 40 km/h {25 mph}: 40 km/
h {25 mph}
Inspect vehicle speedometer sensor.
(See K2–87 VEHICLE SPEEDOMETER
SENSOR (VSS) INSPECTION.)
1V, 1M
Monitor item
(Definition)
Unit/
Condition
Condition/Specification Action
TCM
terminal
