ELECTRONIC 4WD CONTROL SYSTEM
M–71
M
Output Shaft Disassembly Note
1. Remove the coupling unit from the SST.
2. Install the coupling unit to the press as shown,
and remove the output shaft together with the
coupling unit.
3. Install the companion flange to the output shaft.
4. Secure the companion flange using the SST, and
remove the bolts.
5. Remove the output shaft.
Bearing Disassembly Note
1. Remove the bearing using the SSTs and a press.
End Of Sie
A6J63222114
49 S120 710
A6E63222115
49 M005 797
49 S033 108
A6J63222116
To Next Page
