N–16
ENGINE SPEED SENSING POWER STEERING
POWER STEERING OIL PUMP (MZR-CD (RF TURBO)) REMOVAL/INSTALLATION
A6E661432650201
1. Remove the air cleaner.
2. Remove the battery and battery tray.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
.
End Of Sie
OIL
OIL
R
R
R
4
3
1
2
29.4—44.1
{3.00—4.49, 21.7—32.5}
18.6—25.5
{1.90—2.60,
13.8—18.8}
N·m {kgf·m, ft·lbf}
A6E66142006
1 Pressure pipe
2 Return hose
3 Power steering oil pump
4 O-ring
