P–26
ON-BOARD DIAGNOSTIC
DTC C1119
A6E697067650202
DTC C1119 Engine control system, torque reduction inhibit signal line
DETECTION
CONDITION
• Engine RPM information through CAN is out of specification
• Throttle information through CAN is out of specification
• Fuel injection information through CAN is invalid or out of specification (for MZR-CD (RF Turbo) only).
• Received control inhibition signal from PCM through CAN.
POSSIBLE
CAUSE
• Malfunction of PCM
• Malfunction of CAN
PCM
PCM HARNESS SIDE CONNECTOR (L3, L8, LF)
2U
2R
CAN LINE
ABS (ABS/TCS): O
DSC: AG
ABS (ABS/TCS): R
DSC: AF
A
Q
B
C
DE
F
G
H
I
J
DSC HU/CU HARNESS SIDE CONNECTOR
A
C
E
H
K
NQ
T
W
ZAC
AF
FILORU
X
AA
AD
AG
G
J
M
PS
V
Y
AB
AE
AH
B
D
KN
T
WZ
AC
AF
LO
RU
X
AA
AD
AG
MP
S
V
Y
AB
AE
AH
SST (49 G066 001) CONNECTOR
AD AC AB AA
A
Q
B
R
C
S
D
T
E
U
F
V
G
W
H
X
I
Y
JLM
O
P
Z
ABS (ABS/TCS) HU/CM HARNESS SIDE CONNECTOR
AD
AC
AB
AA
A
B
C
D
E
F
G
H
I
J
L
M
O
P
Q
R
S
T
U
V
W
X
Y
Z
SST (49 G066 004) CONNECTOR
PCM HARNESS SIDE CONNECTOR (MZR-CD (RF TURBO))
13
39
L8, LF, L3: 2U
MZR-CD
(RF TURBO): 13
L8, LF, L3: 2R
MZR-CD
(RF TURBO): 39
