LOCATION INDEX
T–17
T
End Of Sie
WARNING AND INDICATOR SYSTEM
A6E810001067201
.
End Of Sie
THEFT-DETERRENT SYSTEM
A6E810050000201
.
End Of Sie
2
1
A6E81181112
1 Fuel gauge sender sub-unit
(See T–27 FUEL GAUGE SENDER UNIT
REMOVAL/INSTALLATION)
(See T–28 FUEL GAUGE SENDER UNIT
INSPECTION)
2 Fuel gauge sender unit
(See T–27 FUEL GAUGE SENDER UNIT
REMOVAL/INSTALLATION)
(See T–28 FUEL GAUGE SENDER UNIT
INSPECTION)
3
1
2
A6E81201102
1 Front intruder sensor (with sliding sunroof)
2 Center intruder sensor (without sliding sunroof)
3 Rear intruder sensor (WGN)
