POWER SYSTEM
T–19
T
RELAY LOCATION
A6E811067730202
.
End Of Sie
RELAY INSPECTION
A6E811067730203
Relay Type
Four-terminal
Type A
1. Remove the relay.
2. Inspect for continuity between the relay terminals
using an ohmmeter.
• If not as specified, replace the relay.
Type B
1. Remove the relay.
2. Inspect for continuity between the relay terminals
using an ohmmeter.
• If not as specified, replace the relay.
End Of Sie
POWER SYSTEM
2
1
A6E81101102
1 Seat warmer relay (with seat warmer) 2 Glow relay (MZR-CD (RF Turbo) only)
Terminal type Part name
Four-terminal
Type A • Seat warmer relay
Type B • Glow relay
CA AE
C
D
E
D
A6E8110W118
: Continuity
Step
1
2
Terminal
E
C
D
A
B+
GND
A6E8110W121
CA
D
B
B
C
A
D
A6E8110W125
: Continuity
Step
1
2
Terminal
B
C
D
A
B+
GND
A6E8110W123
