T–38
AIR BAG SYSTEM
6. Tie all tires together with wire.
7. Connect the SST (Deployment tool) to the SST
(Adapter harness).
8. Connect the red clip of the SST (Deployment tool)
to the positive battery terminal and the black clip
to the negative battery terminal.
9. Verify that the red light on the SST (Deployment
tool) is illuminated.
10. Make sure all persons are standing at least 6 m
{20 ft} from the vehicle.
11. Press the activation switch on the SST
(Deployment tool) to deploy the curtain air bag
module.
End Of Sie
A6E8130W034
49 H066 002
49 L066 002
A6E8130W155
49 H066 002
ACTIVATION
SWITCH
A6E8130W028
