Parameter
Description
Sound option (Computer
speakers are required – not
supplied)
Can indicate various events during stimuli (depending on
protocol used)
CoVAS (Optional)
Computerized Visual Analog Scale (CoVAS) enables real-
time recording of the subject’s pain level, according to the
standard VAS procedure.
MRI Configuration (Optional)
Special accessories and Thermode which can be used in an
MR environment (for specification refer to section 14)
fMRI Thermode and accessories cable length: 10m
fMRI filter body diameter: 70mm
fMRI filter cable length: 2m
External Control(Optional)
Optional control mode, which enables programs to be
initiated from an external application or device. External
Control can be established via Parallel Port or using TCP/IP
network.
Temperature set-point
resolution
0.1°C
Temperature display
resolution
0.1°C
Temperature repeatability
± 0.1°C
Absolute accuracy
± 0.3°C
Ambient temperature in
standard use
18 - 24°C
Communication with
computer
USB
Communication with printer
Via the computer
Computer Requirements
See Separate specifications
Software Operating System
Windows 7, 8, 10 (32/64 bit)
Database
SQL Server Compact Edition (included with software)
Software Language
English
Database capacity
Unrestricted (limited by computer hardware capabilities)
Safety
Complies with UL-2601-1:94 and EN-60601-1-1
