Parameter
Description
Safety limitations on
Temperature & Duration
(1) 56 °C during 0 sec.
(2) 55 °C during 0.05 sec.
(3) 52 °C during 0.4 sec.
(4) 51 °C during 1 sec.
(5) 50 °C during 5 sec.
(6) 49 °C during 10 sec.
(7) 47 °C during 60 sec.
(8) 6 °C during 5min.
(9) 0 °C during 5min.
(10) -10 °C during 5min.
System Configuration
Mobile cart configuration, including electronic box, heavy-
duty External Cooling Unit and 1 KW medical grade isolation
transformer model ISB-100W. (Not including notebook
laptop and printer)
Dimensions
(Mobile cart configuration)
103 × 52 ×61 cm
Weight
(Not including computer)
90-100 Kg (depending on Thermode type)
Operation Voltage
100-120VAC, 60Hz, 4A.
220-240VAC, 50Hz, 2A.
(Via a switchable isolation transformer)
System Overload Protection
2 X 250V, 5A Slo-Blo (for 230V Isolation Transformers).
2 X 120V, 10A Slo-Blo (for 110V Isolation Transformers).
Electronic Box Overload
Protection
2 X 250V, 2A Slo-Blo (for 230V).
2 X 120V, 4A Slo-Blo (for 110V).
Product life time
10 Years
Thermode life time
2 Years
