Functional Description
Microsemi Proprietary and Confidential UG0677 User Guide Revision 9.0 76
Input TX_DISPFNC[0] RESERVED_IN[13]
Input TX_K[7:6] RESERVED_IN[15:14]
Input TX_K[5] RESERVED_IN[16]
Input TX_K[4] TX_SOS
Input TX_K[3:0] TX_HDR[3:0]
Input TX_DATA[63:33] TX_DATA[63:33]
Input TX_DATA[32:19] TX_DATA[32:19]
Input TX_DATA[18:17] TX_DATA[18:17]
Input TX_DATA[16] TX_DATA[16]
Input TX_DATA[15] TX_DATA[15]
Input TX_DATA[14] TX_DATA[14]
Input TX_DATA[13:12] TX_DATA[13:12]
Input TX_DATA[11:10] TX_DATA[11:10]
Input TX_DATA[9:8] TX_DATA[9:8]
Input TX_DATA[7:5] TX_DATA[7:5]
Input TX_DATA[4] TX_DATA[4]
Input TX_DATA[3] TX_DATA[3]
Input TX_DATA[2] TX_DATA[2]
Input TX_DATA[1] TX_DATA[1]
Input TX_DATA[0] TX_DATA[0]
Output RX_K[7] RX_BYPASS_DATA
Output RX_K[6:0] RESERVED_OUT[6:0]
Output RX_CODE_VIOLATION_7 RESERVED_OUT[13:7]
RX_DISPARITY_ERROR_7
RX_CODE_VIOLATION_6
RX_DISPARITY_ERROR_6
RX_CODE_VIOLATION_5
RX_DISPARITY_ERROR_5
RX_CODE_VIOLATION_4
Output RX_DISPARITY_ERROR_4 RX_HDR_VAL
Output RX_CODE_VIOLATION_3 STATUS_HI_BER
Output RX_DISPARITY_ERROR_3 STATUS_LOCK
Output RX_CODE_VIOLATION_2 RX_SOS
Output RX_DISPARITY_ERROR_2 RX_DATA_VAL
Output RX_CODE_VIOLATION_1 RX_HDR[3:0]
RX_DISPARITY_ERROR_1
RX_CODE_VIOLATION_0
RX_DISPARITY_ERROR_0
Table 23 • Port Crossover between the 8b10b and 64b66b Modes
DIRECTION 8B10B MODE 64B6xB MODE
