4 - 9
4 Parameter List
High-function General-purpose Inverter 3G3RX-V1 User’s Manual (I578-E1)
4-3 Extended Function Mode
4
4-3-1 Group A: Standard Function Parameters
Parameter
No.
Function name Monitor or data range
Default
data
Changes during
operation
Unit Page
Normal b031 = 10
A019 Multi-step Speed
Selection
00: Binary (16-step selection with
4 terminals)
01: Bit (8-step selection with 7
terminals)
00 Disabled Disabled – 7-26
A020
1st Multi-step
Speed Reference 0
0.00
Starting Frequency (b082) to 1st
Maximum Frequency (A004)
6.00 Enabled Enabled Hz
A220
2nd Multi-step
Speed Reference 0
0.00
Starting Frequency (b082) to 2nd
Maximum Frequency (A204)
6.00 Enabled Enabled Hz
A320
3rd Multi-step
Speed Reference 0
0.00
Starting Frequency (b082) to 3rd
Maximum Frequency (A304)
6.00 Enabled Enabled Hz
A021 Multi-step Speed
Reference 1
0.00
Starting Frequency (b082) to
1st/2nd/3rd Maximum Frequency
(A004/A204/A304)
0.00 Enabled Enabled Hz
A022 Multi-step Speed
Reference 2
0.00
A023 Multi-step Speed
Reference 3
0.00
A024 Multi-step Speed
Reference 4
0.00
A025 Multi-step Speed
Reference 5
0.00
A026 Multi-step Speed
Reference 6
0.00
A027 Multi-step Speed
Reference 7
0.00
A028 Multi-step Speed
Reference 8
0.00
A029 Multi-step Speed
Reference 9
0.00
A030 Multi-step Speed
Reference 10
0.00
A031 Multi-step Speed
Reference 11
0.00
A032 Multi-step Speed
Reference 12
0.00
A033 Multi-step Speed
Reference 13
0.00
Starting Frequency (b082) to
1st/2nd/3rd Maximum Frequency
(A004/A204/A304)
0.00 Enabled Enabled Hz
A034 Multi-step Speed
Reference 14
0.00
A035 Multi-step Speed
Reference 15
0.00
A038 Jogging
Frequency
0.00
Starting Frequency to 9.99
6.00 Enabled Enabled Hz 7-30
Multi-step speed, jogging
