Setting Sensing
116
ZW-7000/5000
User's Manual
4-1 Setting Sensing
Setting the Measurement Cycle
Set the measurement cycle. Extending the measurement cycle allows you to measure workpieces with lower
reflectivity.
 Multi View Explore : [Bank] | [(Bank data name)] (double-click)
→ Edit pane : [Sensing setting] icon ( )
→ Sensing settings window : [Operating mode]
1 Set [Measurement cycle].
If changing the extension fiber cable length setting causes the setting value of the measurement cycle to exceed the
maximum value, the setting value is automatically changed to the maximum value.
You can set the Measurement cycle by using key operation of the Sensor Controller p.197.
Item Setting item Setting value Description
RUN mode Measurement
Cycle
Refer to the table below. Set the measurement cycle.
Sensor Controller
type
Extension fiber cable
length
Minimum value (1 area
mode) [µs.]
Minimum value (2 area
mode) [µs.]
Maximum value
[µs.]
Initial value [µs.]
ZW-7000@ None 20 40 400 200
2m 400
200
5m 400
200
10m 250
100
20m 160
80
30m 120
60
ZW-5000@ None 80 80 1600 800
2m 1600
800
5m 1600
700
10m 1400
450
20m 900
250
30m 650
200
Important
